Question 59 Discussion

Refer to the exhibits. A NAC policy has been configured to apply traffic that flows through FortiSwitch port 2. Traffic that meets the NAC policy criteria will be assigned to the Students VLAN. However, the NAC policy does not seem to be taking effect. Which configuration is missing? (Choose one answer)

  • A. The Students VLAN should be set to Allowed VLANs instead of Native VLAN.
  • B. Port2 Access mode should be set to Port Policy mode.
  • C. The MAC address or OS might be misconfigured for the connected device.
  • D. Port2 Access mode should be set to NAC mode.
Correct Answer: D

Brave-Dump Clients Votes

D 100%

Comments



kair ahmid 2025-08-16 00:28:17

Selected Answers: D


A NAC policy on a FortiSwitch will only be enforced if the port where the device is connected is configured in NAC mode. In the exhibit, port2 is in Static mode, which means the NAC policy will never be triggered even if the device matches the MAC address or OS pattern. Changing port2’s Access mode to NAC will allow the FortiGate/FortiSwitch to apply the NAC policy and assign the device to the Students VLAN dynamically.
